F19 Clip-on Glass Soft-closing Hinge (One-way)

description
Opening angle: 105
Diameter of hinge cup: Φ35mm
Panel (K) size: 3-7mm
Optional plate thickness: 4-7mm

Material
Hinge Cup: Iron Nickel Plated
Hinge arm: iron nickel plated
Base: Iron and Nickel Plated
Accessories: nylon plastic
