THERE IS ALWAYS A HINGE THAT SUITS YOU
-
X30 Clip-on 155° Soft-closing Hinge
Description
- Compatible with mitered door panels
- Clip-on Installation
- Cam Adjustment
- Two-way function
- Small angle buffer
- Opening Angle: 155°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 11.5mm
- Door(K)dimension: 3-20mm
- Optional door thickness: 15-25mm
- EN15570 Standard
Material
- Steel / Alloy / Nickel plating2026-05-15 -
X31 Clip-on 155° Soft-closing Hinge With 3D Adjustment
Description
- Compatible with mitered door panels
- Clip-on Installation
- 3D Adjustment
- Two-way function
- Small angle buffer
- Opening Angle: 155°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 11.5mm
- Door(K)dimension: 3-20mm
- Optional door thickness: 15-25mm
- EN15570 Standard
Material
- Steel / Alloy / Nickel plating2026-05-15 -
A38 Clip-on 155° Soft-closing Hinge
Description
- Clip-on Installation
- Two-way function
- Opening Angle: 155°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 12mm
- Door(K)dimension: 3-7mm
- Optional door thickness: 16-22mm
Material
- Steel / Plastic / Nickel plating2026-05-15 -
A39 Clip-on 155° Soft-closing Hinge With 3D Adjustment
Description
- Clip-on Installation
- Two-way function
- 3D Adjustment
- Opening Angle: 155°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 12mm
- Door(K)dimension: 3-7mm
- Optional door thickness: 16-22mm
Material
- Steel / Plastic / Nickel plating2026-05-15 -
B29 Slide-on 165° Hinge
Description
- Slide-on Two-way 165° Spring Hinge
- Opening Angle: 165°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 11.5mm
- Door(K)dimension: 3-7mm
- Optional door thickness: 15-22mm
- EN15570 Standard
Material
- Steel / Nickel plating2026-05-15 -
B30 Clip-on 165° Hinge
Description
- Clip-on Two-way 165° Spring Hinge
- Opening Angle: 165°
- Diameter of hinge cup: p35mm
- Depth of hinge cup: 11.5mm
- Door(K)dimension:3-7mm
- Optional door thickness: 15-22mm
- EN15570 Standard
Material
- Steel / Alloy / Nickel plating2026-05-15
Large Angle Hinge Series
-
