Description
- Specially Designed for American Cabinets
- Clip-on Installation
- Integrated mini damper
- Two-way function
- 3D Adjustment
- Small angle buffer
- Opening Angle : 105°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 12.5mm
- Door(k) dimension:3-7mm
- Optional door thickness: 15-25mm

Material
- Steel / Alloy / Nickel plating

Description
- Inseparable Installation
- Integrated mini damper
- One-way function
- 3D Adjustment
- Opening Angle : 105°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 2.5-3mm
- Optional door thickness: 14-26mm
- ANSI / KCMA Standard

Material
- Steel / Plastic / Nickel plating

Description
- Damper Switch
- Inseparable Installation
- Integrated mini damper
- One-way function
- 3D Adjustment
- Opening Angle : 105°
- Diameter of hinge cup :p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 2.5-3mm
- Optional door thickness: 14-26mm
- ANSI / KCMA Standard

Material
- Steel / Plastic / Nickel plating

Description
- Damper Switch
- Inseparable Installation
- Integrated mini damper
- One-way function
- 3D Adjustment
- Opening Angle : 105°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Doorlk dimension: 2.5-3mm
- Optional door thickness: 14-26mm
- ANSI / KCMA Standard

Material
- Steel / Plastic / Nickel plating

Description
- Inseparable Installation
- Integrated mini damper
- One-way function
- 3D Adjustment
- Opening Angle : 105°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Doork) dimension: 2.5-3mm
- Optional door thickness: 14-26mm
- ANSI/ KCMA Standard

Material
- Steel / Plastic / Nickel plating

Description
- Damper Switch
- Inseparable Installation
- Integrated mini damper
- One-way function
- 2D Adjustment
- Opening Angle : 105°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 2.5-3mm
- Optional door thickness: 14-26mm
- ANSI / KCMA Standard

Material
- Steel / Plastic / Nickel plating
