Zhaoqing JinLi Xiangxing Precision Metal Manufacturing Co.,Ltd-Special Angle Hinge Series

BT404A-30° Slide-on Special-Angle Hinge

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 30°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 3-7mm
- Optional door thickness: 15-22mm

Material
- Steel / Nickel plating

2026-05-19
BT404A-45° Slide-on Special-Angle Hinge

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 45°
- Diameter of hinge cup : 35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 3-7mm
- Optional door thickness: 15-22mm

Material
- Steel / Nickel plating

2026-05-19
BT404A-90° Slide-on Secia Angle

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 90°
- Diameter of hinge cup :p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension:3-7mm
- Optional door thickness: 15-22mm

Material
- Steel / Nickel plating

2026-05-19
BT404A-115° Slide-on Special-Angle Hinge

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 115°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension:3-7mm
- Optional door thickness: 15-22mm

Material
- Steel / Nickel plating

2026-05-19
BT404A-135° Slide-on Sneciat Angle

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 135°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension:3-7mm
- Optional door thickness: 15-22mm

Material
- Steel / Nickel plating

2026-05-19
BT404A-180° Slide-on Special-Angle Hinge

Description
- Slide-on Two way Special-angle Spring Hinge
- Opening Angle : 180°
- Diameter of hinge cup : p35mm
- Depth of hinge cup : 11.5mm
- Door(k) dimension: 3-7mm
- Optional door thickness: 15-22mm

Material
- Steel/ Nickel plating

2026-05-19

Special-angle Hinge Series
